This Wide Recessed LED Profile for LED Strip can be recess mounted into spaces where required, and has a diffused cover, which allows light to shine through whilst dispersing the view of individual diodes on the LED tape inside. This gives your LED tape installation a more ‘finished’ look.
Specification | |
Aluminum Profile | 6063-T5 |
Diffuser | PC diffused cover |
Length | 2000mm / 2500mm / 3000mm |
Weight | 1.202kg/m |
Max LED Strip Width | 64mm |
Max Power | 35W/m |
Beam angle | 100° |
Finish | Silver / Black anodized , Powder coated white / black or other colors |
Installation | Recessed |
ALP017-R5
50x35mm Recessed LED Aluminum Profile Channel with PC Opal Diffuser, End Caps and Mounting Accessories, Connector, can do customized length and color.
ALP068-R3
Aluminum profiles for LED strips are perfect for surface or recessed mount application
ALP048-R1
PROFILES EN ALUMINIUM POUR BANDES LED
ALP6875
LED Linear Architectural
ALP018-R3
35mm deep Led strip profile is a u shape led profile for pendant,susface and recessed mounting, suitable for all kinds of LED-strips, can customize 3m, 4m, 5m.
